Leading Beverage Manufacturer Protects Critical SAP ERP in AWS EC2 Cloud

by Leave a Comment

Leading Beverage Manufacturer Protects Critical SAP ERP in AWS EC2 Cloud

Leading Beverage Manufacturer Protects Critical SAP ERP in AWS EC2 Cloud

SIOS Chosen Based on Certifications and Validations for SAP, Amazon Web Services and Red Hat Linux

A leading Hong Kong-based beverage manufacturer produces 61 beverage brands including the number one software drink brand in the world and distributes them to more than 728 million customers throughout Hong Kong, mainland China, Taiwan and western USA.

The Environment

The company relies on an SAP ERP (enterprise resource planning) system running in a Red Hat Linux environment to manage a variety of critical business operations. The SAP environment comprises a variety of services including the ABAP (Advanced Business Application Programming), SAP Central Services (ASCS), Evaluated Receipt Settlement, Web Dispatcher and the DB2 database. They used a large Storage Area Network (SAN) for data storage. The core SAP applications handle all business operations across the company’s beverage division. In their on-premises data center, the company provided uptime protection for this system using data replication and backups of the SAN.

The Challenge

The company’s IT department determined that they could achieve true high availability (99.99% uptime), disaster recovery, scalability and cost savings by migrating to the cloud and using failover clustering to protect their critical SAP system. However, they realized that SAN and other shared storage required for traditional failover clustering is not practical in some clouds and is not available in others.

The Evaluation

After extensive evaluation, the company chose to move their SAP environment to Amazon EC2. They established four key criteria for evaluating their choices for an HA/DR solution. Their solution needed to:

  • Be certified and validated for use with SAP, AWS and Red Hat
  • Provide both high availability and enable high performance
  • Protect against all likely failure scenarios
  • Enable easy ongoing operation and maintenance

The company’s cloud account manager recommended that they consider the SIOS Protection Suite, offered through AWS China. The SIOS software is certified by SAP for both NetWeaver and DB2, and that SIOS is fully tested and supported on Red Hat Enterprise and other distributions of Linux. The company tested the SIOS clustering software extensively under a variety of challenging failure scenarios, and also evaluated the throughput performance during periods of peak demand. The IT team’s confidence in SIOS Protection Suite increased as it passed each of their rigorous tests and proved to be remarkably easy to use.

The Solution

SIOS Protection Suite for Linux enables SANless failover clustering to provide full HA and DR for SAP and its critical services. The SIOS software uniquely includes modules called Application Recovery Kits (ARKs) that provide application-specific functionality that simplifies configuration and ensures failover orchestration maintains application best practices. The SAP and HANA ARKs automate configuration steps and validate configuration inputs and manage IP failover, and boot order to minimize human error. Unlike other clustering software that only validates server operability, the SIOS clustering software verifying that SAP and critical services are running, that databases are mounted and available, that any file shares or exports are available, and that clients are able to connect. To ensure these services are all functioning properly, SIOS software continuously monitors the servers, virtual machines, operating system and all major components of the SAP software. For DR protection, the company located the active and standby cluster nodes in different AWS Availability Zones for geographical separation.

The Results

SIOS Protection Suite has made it possible for this leading beverage manufacturer to meet the stringent recovery time and recovery point objectives established for its SAP/DB2 environment. To date, the configuration has experienced no perceptible downtime, including during planned maintenance. And these results have been realized with minimal effort, making it possible for the IT staff to focus more on projects that enhance employee productivity or otherwise improve business operations.

Reproduced with permission from SIOS

Video: High Availability for Building Management and Security

by Leave a Comment

Video: High Availability for Building Management and Security

This video covers high availability for building maintenance and security, featuring Harry Aujla, technical director at SIOS. Building Management System (BMS) solutions are software-based solutions running on hardware, designed and built with varying degrees of autonomy and intelligence. BMS can either be hosted on-site or off-site at a geographically distant control center.

The BMS sector is at the cusp of another technical evolution as its customers are looking at how the cloud is changing the operating landscape. The market is now sufficiently mature in that many of the cloud vendors now offer secure and redundant connections to their platforms. There’s an implicit trust that BMS related data is being securely transmitted to and from the cloud. A lot of BMS companies are running in the cloud as well.

To define your SLSs before customers embark on a high availability project is important. If we have an instance running in the cloud where our BMS solution is running and this instance for whatever reason happens to fail, the cloud vendors will take necessary actions to recover the instance. But what happens if you suffer an application software issue within the cloud instance? You need a way of monitoring application level failures and orchestrating their recovery. It’s important to consider adding a high availability clustering solution like SIOS that can address the application level high availability needs which can then contribute towards maintaining application performance.

Reproduced with permission from SIOS

Understanding and Avoiding Split Brain Scenarios

by Leave a Comment

Understanding and Avoiding Split Brain Scenarios

Split brain. Most readers of our blogs will have heard the term, in the computing context that is, yet we cannot help but to sympathize with those whose first mental image is of the chaos that would result if someone had two brains, both equally in control at the same time.

What is a Failover Cluster Split Brain Scenario?

In a failover cluster split brain scenario, neither node can communicate with the other, and the standby server may promote itself to become an active server because it believes the active node has failed. This results in both nodes becoming ‘active’ as each would see the other as being failed. As a result, data integrity and consistency is compromised as data on both nodes would be changing. This is referred to as split brain.

There are two types of split-brain scenarios which may occur for an SAP HANA resource hierarchy if appropriate steps are not taken to avoid them.

  • HANA Resource Split Brain: The HANA resource is Active (ISP) on multiple cluster nodes. This situation is typically caused by a temporary network outage affecting the communication paths between cluster nodes.
  • SAP HANA System Replication Split Brain: The HANA resource is Active (ISP) on the primary node and Standby (OSU) on the backup node, but the database is running and registered as the primary replication site on both nodes. This situation is typically caused by either a failure to stop the database on the previous primary node during failover, having Autostart enabled for the database, or a database administrator manually running “hdbnsutil -sr_takeover” on the secondary replication site outside of the clustering software environment.

Avoiding Split Brain Issues

Recommendations for avoiding or resolving each type of split-brain scenario in the SIOS Protection Suite clustering environment are given below.

While in a split-brain scenario, a message similar to the following is logged and broadcast to all open consoles every quickCheck interval (default 2 minutes) until the issue is resolved.

EMERG:hana:quickCheck:HANA-SPS_HDB00:136363:WARNING:
A temporary communication failure has occurred between servers
hana2-1 and hana2-2.
Manual intervention is required in order to minimize the risk of
data loss.
To resolve this situation, please take one of the following resource
hierarchies out of service: HANA-SPS_HDB00 on hana2-1
or HANA-SPS_HDB00 on hana2-2.
The server that the resource hierarchy is taken out of service on
will become the secondary SAP HANA System Replication site.

Recommendations for resolution:

  1. Investigate the database on each cluster node to determine which instance contains the most up-to-date or relevant data. This determination must be made by a qualified database administrator who is familiar with the data.
  2. The HANA resource on the node containing the data that needs to be retained will remain Active (ISP) in LifeKeeper, and the HANA resource hierarchy on the node that will be re-registered as the secondary replication site will be taken entirely out of service in LifeKeeper. Right-click on each leaf resource in the HANA resource hierarchy on the node where the hierarchy should be taken out of service and click Out of Service …
  3. Once the SAP HANA resource hierarchy has been successfully taken out of service, LifeKeeper will re-register the Standby node as the secondary replication site during the next quickCheck interval (default 2 minutes). Once replication resumes, any data on the Standby node which is not present on the Active node will be lost. Once the Standby node has been re-registered as the secondary replication site, the SAP HANA hierarchy has returned to a highly available state.

SAP HANA System Replication Split Brain Resolution

While in this split-brain scenario, a message similar to the following is logged and broadcast to all open consoles every quick. Check interval (default 2 minutes) until the issue is resolved.

EMERG:hana:quickCheck:HANA-SPS_HDB00:136364:WARNING:
SAP HANA database HDB00 is running and registered as
primary master on both hana2-1 and hana2-2.
Manual intervention is required in order to
minimize the risk of data loss. To resolve this situation,
please stop database instance
HDB00 on hana2-2 by running the command ‘su – spsadm -c
“sapcontrol -nr 00 -function Stop”’
on that server. Once stopped,
it will become the secondary SAP HANA System Replication site.

Recommendations for resolution:

  1. Investigate the database on each cluster node to determine whether important data exists on the Standby node which does not exist on the Active node. If important data has been committed to the database on the Standby node while in the split-brain state, the data will need to be manually copied to the Active node. This determination must be made by a qualified database administrator who is familiar with the data.
  2. Once any missing data has been copied from the database on the Standby node to the Active node, stop the database on the Standby node by running the command given in the LifeKeeper warning message:

    su – adm -c “sapcontrol -nr <Inst#> -function Stop”

    where is the lower-case SAP System ID for the HANA installation and <Inst#> is the instance number for the HDB instance (e.g., the instance number, for instance, HDB00 is 00)

  3. Once the database has been successfully stopped, LifeKeeper will re-register the Standby node as the secondary replication site during the next quickCheck interval (default 2 minutes). Once replication resumes, any data on the Standby node which is not present on the Active node will be lost. Once the Standby node has been re-registered as the secondary replication site, the SAP HANA hierarchy has returned to a highly available state.

Being aware of common split-brain scenarios and taking these steps to mitigate them can save you time and protect data integrity.

Reproduced with permission from SIOS

SIOS Protection Suite for Linux Quick Service Protection

by Leave a Comment

How to add custom application support to SIOS Protection Suite - SIOS Protection Suite for Linux Quick Service Protection

Using SIOS Protection Suite for Linux Quick Service Protection Resource

On a recent engagement with the SIOS Professional Services team, a customer inquired about how to protect a custom application with the SIOS Protection Suite for Linux solution. One of the highly experienced high availability experts at SIOS Technology Corp., helped understand the customer’s application and laid out the methods SIOS provides for custom application support.

SIOS Protection Suite for Linux provides multiple methods for adding high availability and application monitoring to custom applications.  These options include the following:

  • Creating a custom application recovery kit (ARK)1
  • Creating a generic application resource hierarchy
  • Creating a quick service protection resource
Type Coding Complexity Monitoring Recovery
Custom Application Recovery Kit Resource1 Highest Highest Highest
Generic Application Resource Medium High High
Quick Service  Protection Resource Low Medium Medium

Definitions Used in Chart

Monitoring – defined as the ability to make a determination of the availability, accessibility and functioning of the protected application, database or service.  A low level of application, database, or service monitoring provides basic coverage, such as a check for a running process, existence of a pid_file, or that the status command returns a ‘true’ result when executed.  Note: A ‘true’ or ‘0 (zero)’ return code does not mean that the application, database, or service is running. But only that the command executed was able to successfully complete with a positive (‘true’ or ‘0 (zero)’) status result.  The highest level of monitoring indicates that application specific knowledge is applied to determine the health and functioning of the application beyond lower level methods such as process status, ps output, or systemd status returns.  The highest level of monitoring typically applies knowledge of recommended order of healthcheck operations, knowledge of dependencies, and analysis of the results obtained from status and monitoring commands.

Recovery – defined as the ability to restart a failed application, database or service.  A low level of recovery capability implies that commands for a restart are issued and expected output are obtained from the issuance of the command.  The highest level of monitoring indicates that application-specific knowledge is applied to determine how to initiate an orderly restart of the application, database, or service, which may require knowledge of recommended order of operations, dependencies, rollbacks or other related remediation of a failed service.

Solution:  Quick Service Protection Resource

In this engagement, the customer’s application had systemd compatibility. Based on their overall requirements for avoiding coding, minimal monitoring needs, and simple recovery procedures, we recommended the Quick Service Protection (QSP) Resource.

The QSP resource works to quickly add support of a systemd service to the SIOS Protection Suite for Linux resource protection.  In the case of Customer Example.com, they have a systemd compatible service, with the minimal required definition needed to start and stop their application.

[Unit]

Description=SIOS ‘as-is’ Example Service 2020

After=network.target

[Service]

Type=simple

Restart=always

RestartSec=3

User=root

ExecStart=/example_app/bin/exampleapp start

ExecStop=/example_app/bin/exampleapp stop

[Install]

WantedBy=multi-user.target

Example.com systemd file

SIOS recommends that prior to attempting the protection of the resource with the SIOS Protection Suite for Linux product, verify via systemctl that the example application stops and starts accordingly:

# systemctl status example

* example.service – SIOS ‘as-is’ Example Service 2020

Loaded: loaded (/usr/lib/systemd/system/example.service; disabled; vendor preset: disabled)

Active: inactive (dead)

# systemctl start example

# systemctl status example

* example.service – SIOS ‘as-is’ Example Service 2020

Loaded: loaded (/usr/lib/systemd/system/example.service; disabled; vendor preset: disabled)

Active: active (running) since Fri 2020-08-21 14:53:27 EDT; 5s ago

Main PID: 19937 (exampleapp)

CGroup: /system.slice/example.service

`-19937 /usr/bin/perl /example_app/bin/exampleapp start

# systemctl stop example

# systemctl status example

* example.service – SIOS ‘as-is’ Example Service 2020

Loaded: loaded (/usr/lib/systemd/system/example.service; disabled; vendor preset: disabled)

Active: inactive (dead)



After verifying that the application functions correctly via systemd, restart the service and ensure that the service is running.

# systemctl start example

# systemctl status example

* example.service – SIOS ‘as-is’ Example Service 2020

Loaded: loaded (/usr/lib/systemd/system/example.service; disabled; vendor preset: disabled)

Active: active (running) since Fri 2020-08-21 15:59:44 EDT; 3min 2s ago

Main PID: 30740 (exampleapp)

Refer to the SIOS Protection Suite for Linux Quick Service Protection Suite documentation for additional details on the resource create process.

Using the SPS-L UI select the Create option, indicated in the Global UI Resource Toolbar by the following icon:   SIOS Global US Resource

Once the create wizard is launched, select the Quick Service Protection option in the Create Resource Wizard Window



In the next prompt for  ‘Switchback Type’, choose whether you will use intelligent switchback or automatic switchback.

After selecting the ‘Switchback Type’,  the Server dialogue appears allowing you to choose the primary server for the custom application.



(Note: If the service requires storage, be sure to choose the same primary server previously selected for the storage resources.)

In the Service Name dialog box, find the service for your custom application.

Once you’ve selected the correct service, example, determine whether you will enable monitoring or disable the monitoring service.  Refer to the documentation to gain an understanding of the monitoring provided by the QSP resource.2



Next, choose a resource tag.  A resource tag should be a meaningful name that will help your IT team quickly identify which SPS-L resource protects your application or service.

Lastly, follow the final dialogue to complete the resource creation process.  Once the resource is created, use the UI to extend the resource to additional servers. If necessary, create dependencies between the newly protected custom service/application and any other required resources such as storage or IP resources.



NOTES:

1 Creating a customer application recovery kit can be accomplished via an engagement with the SIOS Technology Corp. Professional Services Team.  For more information contact professional-services@us.sios.com

2 The QSP Recovery Kit quickCheck can only perform simple health (using the “status” action of the service command). QSP doesn’t guarantee that the service is provided or the process is functioning. If complicated starting and/or stopping is necessary, or more robust health checking operations are necessary, using a Generic Application or Custom Application ARK is recommended
