How to Achieve High Availability with Clusters

December 3, 2021 by Jason Aw Leave a Comment

How to Achieve High Availability with Clusters

What is High Availability?

High availability (HA) is a component of a technology system that eliminates single points of failure to ensure continuous operations or uptime for an extended period. High availability clusters are groups of servers that support business-critical applications that require minimal downtime and continuous availability.

All organizations use a variety of business-critical databases and applications, such as data warehouses, e-commerce applications, customer relationship management systems (CRM), financial systems, supply chain management, and business intelligence systems. When a system, database, or application fails, these organizations require high availability protection to keep systems up and running and minimize the risk of lost revenue, unproductive employees, and unhappy customers.

Highly available clusters incorporate five design principles:

They automatically failover to a redundant system to pick up an operation when an active component fails. This eliminates single points of failure.
They can automatically detect application-level failures as they happen, regardless of the causes.
They ensure no amount of data loss during a system failure.
They automatically and quickly failover to redundant components to minimize downtime.
They provide the ability to manually failover and failback to minimize downtime during planned maintenance.

TechTarget defines HA as “a system or component that is continuously operational for a desirably long length of time. Availability can be measured relative to ‘100% operational’ or ‘never failing.’ A widely-held but difficult-to-achieve standard of availability for a system or product is known as ‘five 9s’ (99.999%) availability.”

But let’s define High Availability in simple terms:

High Availability ensures your systems, databases, and applications operate when and as needed.

The “when” takes into consideration the percentage of time the application must be up and running. The “as needed” takes into consideration the proper operation of the system, database, and/or applications with no data loss.

Depending on the system and/or application, high availability will be different. For example, with mission-critical applications, such as your eCommerce systems, four 9s’ (99.99%) availability is considered an industry standard. With 99.99% availability, you can expect no more than 52.60 minutes of downtime per year or 8.64 seconds of downtime per day. However, for non-critical applications and systems, such as a single desktop failure, high availability may be two 9s (99%), which equates into 8.77 hours of downtime per year or 1.44 minutes of downtime per day. When measuring acceptable downtime, it is important that you consider:

Unplanned downtime (e.g., hardware or software failures)
The planned downtime needed for routine hardware and software maintenance
Uptime at the database and application level

Your choice for high availability is dependent on many factors, including how critical the applications are to the business, whether customers are impacted, how often the applications run, how many users are affected, how quickly a database or application must failover to the redundant system, and how much data loss is tolerable.

High Availability Metrics: RTO and RPO

The two metrics normally used to assess HA (and Disaster Recovery (DR) as well) are the Recovery Time Objective (RTO) and the Recovery Point Objective (RPO).

RTO is the maximum tolerable duration of any outage. Online transaction processing applications generally have the lowest RTOs, and those that are mission-critical often have an RTO of only a few seconds.
RPO is the maximum amount of data loss that can be tolerated when a failure happens. For HA, RPO is often zero to specify there should be zero data loss under all failure scenarios.

However, there is a difference between what RTOs and RPOs you can achieve to support high availability versus disaster recovery. With HA, data replication can be synchronous because your redundant components are on your LAN environment. Active and standby databases can be concurrently updated, enabling full, automatic, real-time recoveries that can satisfy the most demanding RTOs and RPOs. As a result, your standby instance is “hot” and in sync with your active instance, so it is ready to immediately take over in the event of a failure.

However, to recover systems, software, and data in the event of a disaster requires redundant components to be on a wide-area network (WAN). This is important because you must keep redundant components in a geographic location away from the active instance. But with a WAN, data replication is asynchronous to avoid negatively impacting throughput performance. This means that updates to standby instances will lag updates made to the active instance, resulting in a delay during the recovery process. Since disasters are rare, some delay may be tolerable and is dependent upon (a) how critical it is to your business to achieve the lowest possible RTO and RPO and (b) how much budget you can allocate to achieve the best RTO and RPO.

How SIOS Helps You Achieve High Availability

SIOS offers a single solution to meet both high availability and disaster recovery needs across a wide variety of operating systems, infrastructure environments, and applications, including SAP, SQL Server, Oracle, and other environments running in SAN-based, shared storage configurations or SANless, local data storage configurations.

Windows Environment: When added to a Windows Server Failover Cluster (WSFC) environment, SIOS DataKeeper lets you create a SANless cluster, where shared storage clusters are impossible or impractical, or add replication for disaster protection in your SAN-based Windows clusters. Fast, efficient host-based replication synchronizes local storage on local and remote cluster nodes, creating a SANLess cluster in any combination of physical, virtual, or cloud environments.
Linux Environments: SIOS Protection Suite for Linux is a packaged clustering software solution that uses SIOS LifeKeeper and SIOS DataKeeper to provide a tightly integrated combination of high availability failover clustering, continuous application monitoring, data replication, and configurable recovery policies to protect your business-critical applications and data from downtime and disasters. SIOS Protection Suite lets you build SAN or SANLess clusters using a wide range of storage devices, including direct-attached storage, iSCSI, and Fibre Channel. SIOS Protection Suite for Linux supports all major Linux distributions, including Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, and Oracle Linux.

With SIOS solutions, RPO is always zero and RTO is dependent on the application but typically 30 seconds to a few minutes for some applications. Let’s discuss one customer’s “SIOS in action” case study using HA clusters at Switzerland’s largest retail company.

Migros Achieves Critical Business Continuity of its POS system with SIOS High Availability Solutions

Migros is Switzerland’s largest retail company, its largest supermarket chain, and the largest employer with more than 100,000 employees. It is also one of the forty largest retailers in the world. Partnering with Realstuff Informatik AG, a Switzerland-based IT service provider and reseller of SIOS solutions, Migros was looking to replace its Point of Sale (POS) system with a new platform that was more efficient to operate and could minimize the threat of downtime.

The new POS system provides price and product assortment information in Migros’ 650 stores and the retailer needed a high availability solution to support day-to-day sales. Without an HA system, employees could not price products or weigh goods if there was a system failure, bringing operations to a standstill. After evaluating options, Migros decided it wanted an open-source server environment that offered high availability and continuous data protection, was independent of a virtual environment, and could be internally operated by the company’s IT staff. To address these requirements, the team picked SIOS Protection Suite for Linux for replication to safeguard POS data.

For system design, customer training, and native language support, Realstuff partnered with the SIOS Competence and Support Center for Central and Eastern Europe, based in Dresden, Germany and operated by Computer Concept. It was important to Migros to get 24x7x365 support during the regional office time from the Competence and Support Center.

Realstuff implemented the SIOS Protection Suite high-availability solution to constantly monitor the POS servers and replicate data. At each store location, two servers are used to ensure continuous data protection. If one server fails, the second instance takes over the work instantaneously. In addition, both servers mirror data assets on the monitoring system. Read the full Migros case study here.

Final Thoughts

The regional Competence and Support Center consulted with Realstuff to provide insight and direction on the implementation and launch and conducted a three-day training workshop to train the Migros team. Richard Huber, manager and a member of the executive board at Realstuff, commented post-deployment that the benefits of the SIOS high availability solution were its flexibility, reliability, ease of use, and assurance that data is kept in sync at all times.

Today, Migros has met its requirements for HA with SIOS easy-to-use solution, which provides continuous monitoring of servers, storage, applications, databases, and network connections to detect points of failure, reduce downtime, maintain client connectivity, and provide uninterrupted data access.

For more information on SIOS solutions and how SIOS can help you achieve HA in a SQL Server environment, you can read “Why Clustering for SQL Server High Availability” here.

Reproduced from SIOS

Four Reasons To Use An Avoidance Strategy In High Availability

November 28, 2021 by Jason Aw Leave a Comment

Four Avoidance Strategies for Improving Cluster Resilience, Performance, and Outcomes

Simple Steps for Deployment in SIOS Protection Suite Cluster Environment

Avoiding something – we’ve all done it before. An old flame we see in the store while walking with our spouse, a salesperson when we aren’t “ready to buy”, and even a boss while we are out on “vacation”. When I was the manager of a development team, I caught a glimpse of a direct report browsing in a store while they were supposed to be out of the office sick. They ducked between clothing racks and scurried down the next aisle and hurried away. We’ve all done it before, and in some cases, for mental health, physical health, or reasons that remain private and personal, we all need some measures of avoidance. Even in HA. So, how do you add avoidance to your High Availability environment, and why?

Four reasons to use an avoidance strategy in High Availability

Better Performance (minimizing server overload)

One reason to use avoidance strategies in HA is to increase application and server performance. Consider the case of three servers running production workloads, let’s call them Server Alpha, Server Beta, Server Gamma. Servers Alpha and Beta are running critical applications backed by a database, while Server Gamma is running reports and data transformation jobs. In the event of a failure of Server Alpha, a failover to Server Beta would traditionally occur. However, because server Beta is already running a large workload, the resulting additional application load might result in an undesirable server overload and poor performance for both applications. So it might be wise to deploy an avoidance strategy to make sure that Server Gamma is chosen as the failover target.

Performance Optimization

Consider again the scenario of three servers, Alpha, Beta, and Gamma. Servers Alpha and Beta are scaled to handle peak workloads, while Server Gamma is a cost-optimized server. In the event of a failure of Server Alpha and Server Beta, a failover will occur to the cost-optimized server, Gamma. However, this server is not scaled to handle peak workloads, nor the workloads of both Server Alpha and Server Beta at the same time. In this instance, an avoidance strategy can be used to optimize performance by automatically moving one or both of the workloads from Server Gamma as soon as another host is available.

HA Optimization

HA Optimization is another scenario for deploying avoidance strategies. Like the performance optimization strategy, HA optimization is used to ensure that your environment can survive most failure scenarios and that your applications are optimized to provide the highest level of availability possible at any point in time. HA optimization is important for an application such as SAP with replicated enqueue processes. In any SAP environment, you do not want the ASCS (ABAP SAP Central Service) and ERS (enqueue replication services) instance residing on the same server for extended periods of time because of the risk of lost locks and canceled jobs. To prevent this from occurring you can use an avoidance strategy that causes the ERS and ASCS instances to always run on opposite cluster nodes. Consider the case of three servers running production workloads, let’s call them Servers Alpha, Beta, Gamma. Server Alpha is running the ASCS instance, while Server Beta is running the ERS instance. Server Gamma functions as a third node for failovers of both Server Beta (ERS) and Server Alpha (ASCS). If Beta crashes, you wouldn’t want the ERS resource running on the same node as the ASCS instance. To ensure this operation, you can deploy an avoidance strategy that automatically checks first and ensures the two applications are on separate servers, and maintain SAP ASCS/ERS best practices for lock failover.

DR Avoidance

Suppose you have two data centers: City Alpha and City Beta which are about 70 miles apart with most of your clients centrally located between them. However, due to recent changes in internal organizations, mergers/closures and acquisitions, and governance requirements, your IT team has to add a third data center that is located in City Gamma, which is about 350 miles from Alpha and Beta. Now the resources which were primarily protected in Alpha and Beta are also extended to the Gamma location. Given that most of the users and teams are near the Alpha and Beta locations and even the most extreme users are located in neighboring cities, your team needs to avoid a failover to the Gamma location. Like the other strategies, a DR avoidance seeks to optimize performance, in/out regional data costs, latency, and client access by avoiding the DR node should only one node within either region fail. It would also ensure that even if both nodes fail after different times, failover always occurs to the other node in the cluster or data center before moving to DR.

So, how do you deploy an avoidance strategy?

Many providers have affinity rules that can be configured, while others use a combination of server priorities or manual steps. In the case of the SIOS Protection Suite for Linux, you can use a number of built-in methods including:

Resource prioritization

In the event of a failure, resources will fail over to the server where they have the lowest remaining priority and cascade to any additional servers (Alpha, Beta, and Gamma). Server Alpha is the primary server for Resource.HR, Server Beta is the primary server for Resource.MFG, and Server Gamma is the backup server for all resources/servers. Using resource prioritization, Resource.HR would have a priority of one (1) on Server Alpha and a priority of two (2) on Server Gamma. While Resource.MFG could have a priority one (1) on Server Beta and a priority of two (2) on Server Gamma. If customers wanted to optimize the use of the environment, then Resource.HR could have a priority of three (3) on Server Beta and Resource.MFG could have a priority of three (3) on Server Alpha. In the event of a failure of Server Alpha, the resource Resource.HR would fail to Server Gamma first before trying to come in-service (be restored) on Server Alpha.

SIOS Protection Suite for Linux (UI and CLI) allow users to specify a priority for each server and resource combination.

Policy or affinity rules

Policy rules can also be used to prevent a resource recovery from occurring on a given server and thereby allowing a resource to avoid a specified server that may be running a more critical or resource-intensive workload. Typical policies include:

- - - - Constraint policies that will block an application from a specific server by default.

        Resource policies that will block an application from a server that does not have sufficient resources

        Temporal policies that define a time period that resources are allowed or disallowed from a system

        Custom policies that define preferred servers or possible application ownership abilities within the cluster

The SIOS Protection for Linux CLI allows users to specify policy rules which can disable failover to a specific resource for a specified server, provide temporal policies guarding failures, disable failures of a specific application type, constraint policies, and custom policies.

Specific Avoidance Resources

The most granular way to establish a resource avoidance strategy is to deploy specific avoidance scripts within each hierarchy. This method will allow the user to configure specific applications, (eg app1 and app2), to avoid one another whenever possible while allowing other applications to run without restriction. In the case of our three servers, Alpha, Beta, and Gamma, and three resources app1, app2, and app3 this method would provide the greatest flexibility. In this example, app1 and app2 will seek to avoid collocation when a server fails, but app3 will fail to the next available node based on priorities without any collocation restrictions.

For additional examples of avoidance strategies and resources, consider the SIOS Protection Suite for Linux documentation. If a customer has two applications, app1 and app2, that they require to run on different nodes whenever possible, the customer can create two avoidance terminal leaf node resources using the SIOS Protection Suite for Linux gen/app resource and the ‘/opt/LifeKeeper/lkadm/bin/avoid_restore’ script.

Reproduced from SIOS

High Availability & the Cloud: The More You Know

October 25, 2021 by Jason Aw Leave a Comment

High Availability & the Cloud: The More You Know

While researching reasons to migrate to the cloud, you’ve probably learned that the benefits of cloud computing include scalability, reliability, availability, and more. But what, exactly, do those terms mean? Let’s consider high availability (HA), as it is often the ultimate goal of moving to the cloud for many companies.

The idea is to make your products, services, and tools accessible to your customers and employees at any time from anywhere using any device with an internet connection. That means ensuring your critical applications are operational – even through hardware failures, software issues, human errors, and sitewide disasters – at least 99.99% of the time (that’s the definition of high availability).

While public cloud providers typically guarantee some level of availability in their service level agreements, those SLAs only apply to the cloud hardware. There are many reasons for application downtime that aren’t covered by SLAs. For this reason, you need to protect these applications with clustering software that will detect issues and reliably move operations to a standby server if necessary. As you plan what and how you will make solutions available in the cloud, remember that it is important that your products and services and cloud infrastructure are scalable, reliable, and available when and where they are needed.

Quick Stats on High Availability in the Cloud in 2021

Now that we’ve defined availability in the cloud context, let’s look at its impact on organizations and businesses. PSA, these statistics may shock you, but don’t fret. We’ve also got some solutions to these pressing and costly issues.

As much as 80% of Enterprise IT will move to the cloud by 2025 (Oracle).
The average cost of IT downtime is between $5,600 and $11,600 per minute (Gartner; Comparitech).
Average IT staffing to employee ratio is 1:27 (Ecityworks).
22% of downtime is the result of human error (Cloudscene).
In 2020, 54% of enterprises’ cloud-based applications moved from an on-premises environment to the cloud, while 46% were purpose-built for the cloud (Forbes).
1 in 5 companies don’t have a disaster recovery plan (HBJ).
70% of companies have suffered a public cloud data breach in the past year (HIPAA).
48% of businesses store classified information on the cloud (Panda Security).
96% of businesses experienced an outage in a 3-year period (Comparitech).
45% of companies reported downtime from hardware failure (PhoenixNAP).

What You Can Do – Stay Informed

If you are interested in learning the fundamentals of availability in the cloud or hearing about the latest developments in application and database protection, join us. The SIOS Cloud Availability Symposium is taking place Wednesday, September 22nd (EMEA) and Thursday, September 23rd (US) in a global virtual conference format for IT professionals focusing on the availability needs of the enterprise IT customer. This event will deliver the information you need on application high availability clustering, disaster recovery, and protecting your applications now and into the future.

Cloud Symposium Speakers & Sessions Posted

We have selected speakers presenting a wide range of sessions supporting availability for multiple areas of the data application stack. Check out the sessions posted and check back for additional presentations to be announced! Learn more

Register Now

Whether you are interested in learning the fundamentals of availability in the cloud or hearing about the latest developments in application and database protection, this event will deliver the information you need on application high availability clustering, disaster recovery, and protecting your applications now and into the future.

Reproduced from SIOS

Enhanced High Availability for SAP S/4HANA in Cloud Environments

October 16, 2021 by Jason Aw Leave a Comment

SIOS Protection Suite for Linux Now Features Enhanced High Availability for SAP S/4HANA in Cloud Environments

SIOS is pleased to announce the GA release of SIOS Protection Suite for Linux version 9.5.2 clustering software. Our latest release features enhanced automation and application failover orchestration that makes creating and managing high availability (HA) clusters in complex SAP S/4HANA environments easier and more reliable for enterprises.

New features and capabilities in SIOS Protection Suite for Linux 9.5.2, include:

Enhanced, comprehensive Support for high availability in Google Cloud Platform with the addition of SIOS Internal Load Balancer tool designed to orchestrate efficient IP management during switchovers and failovers.
Enhanced ability to automate interactions with SIOS LifeKeeper with products such as Ansible.
Near-Zero Downtime for Switchover During Planned Maintenance. Supports a HANA “Takeover with Handshake” eliminating the potentially time-consuming process of shutting down the primary HANA server database for switchover, allowing to perform planned maintenance without disrupting ongoing service to end-users.
Empowering customers by making SAP logging easier to use and take action on.

Schedule a personalized demonstration here.

Reproduced from SIOS

Deployment of a SQL Server Failover Cluster Instance on Huawei Cloud

September 28, 2021 by Jason Aw Leave a Comment

Deployment of a SQL Server Failover Cluster Instance on Huawei Cloud

*DISCLAIMER: While the following completely covers the high availability portion within the scope of our product, this is a setup “guide” only and should be adapted to your own configuration.

Overview

HUAWEI CLOUD is a leading cloud service provider not just in China but also has global footprint with many datacenters around the world. They bring Huawei’s 30-plus years of expertise together in ICT infrastructure products and solutions and are committed to providing reliable, secure, and cost-effective cloud services to empower applications, harness the power of data, and help organizations of all sizes grow in today’s intelligent world. HUAWEI CLOUD is also committed to bringing affordable, effective, and reliable cloud and AI services through technological innovation.

DataKeeper Cluster Edition provides replication in a virtual private cloud (VPC) within a single region across availability zones for the Huawei cloud. In this particular SQL Server clustering example, we will launch four instances (one domain controller instance, two SQL Server instances and a quorum/witness instance) into three availability zones.

Huawei Cloud SIOS Datakeeper HA Architecture

DataKeeper Cluster Edition provides support for a data replication node outside of the cluster with all nodes in Huawei cloud. In this particular SQL Server clustering example, four instances are launched (one domain controller instance, two SQL Server instances and a quorum/witness instance) into three availability zones. Then an additional DataKeeper instance is launched in a second region including a VPN instance in both regions. Please see Configuration of Data Replication From a Cluster Node to External DR Site for more information. For additional information on using multiple regions please see Connecting Two VPCs in Different Regions.

Huawei Cloud SIOS Datakeeper DR architecture

DataKeeper Cluster Edition also provides support for a data replication node outside of the cluster with only the node outside of the cluster in Huawei Cloud. In this particular SQL Server clustering example, WSFC1 and WSFC2 are in an on-site cluster replicating to a Huawei Cloud instance. Then an additional DataKeeper instance is launched in a region in Huawei Cloud. Please see Configuration of Data Replication From a Cluster Node to External DR Site for more information.

Huawei Cloud SIOS Datakeeper Hybrid DR Architecture

Requirements

Description	Requirement
Virtual Private Cloud	In a single region with three availability zones
Instance Type	Minimum recommended instance type: s3.large.2
Operating System	See the DKCE Support Matrix
Elastic IP	One elastic IP address connected to the domain controller
Four instances	One domain controller instance, two SQL Server instances and one quorum/witness instance
Each SQL Server	ENI (Elastic Network Interface) with 4 IPs · Primary ENI IP statically defined in Windows and used by DataKeeper Cluster Edition · Three IPs maintained by ECS while used by Windows Failover Clustering , DTC and SQLFC
Volumes	Three volumes (EBS and NTFS only) · One primary volume (C drive) · Two additional volumes o One for Failover Clustering o One for MSDTC

Release Notes

Before beginning, make sure you read the DataKeeper Cluster Edition Release Notes for the latest information. It is highly recommended that you read and understand the DataKeeper Cluster Edition Installation Guide.

Create a Virtual Private Cloud (VPC)

A virtual private cloud is the first object you create when using DataKeeper Cluster Edition.

*A virtual Private Cloud (VPC) is an isolated private cloud consisting of a configurable pool of shared computing resources in a public cloud.

Using the email address and password specified when signing up for Huawei Cloud, sign in to the Huawei Cloud Management Console.
From the Services dropdown, select Virtual Private Cloud.

On the right side of the screen, click on Create VPC and select the region that you want to use.
Input the name that you want to use for the VPC
Define your virtual private cloud subnet by entering your CIDR (Classless Inter-Domain Routing) as described below
Input the subnet name, then click Create Now.

*A Route Table will automatically be created with a “main” association to the new VPC. You can use it later or create another Route Table.

*HELPFUL LINK:
Huawei’s Creating a Virtual Private Cloud (VPC)

Launch an Instance

The following walks you through launching an instance into your subnet. You will want to launch two instances into one availability zone, one for your domain controller instance and one for your SQL instance. Then you will launch another SQL instance into another availability zone and a quorum witness instance into yet another availability zone.

*HELPFUL LINKS:
Huawei Cloud ECS Instances

Using the email address and password specified when signing up for Huawei Cloud, sign in to the Huawei Cloud Management Console.
From the Service List dropdown, select Elastic Cloud Server.

Select Buy ECS button and choose the Billing Mode, Region and AZ (Availability Zone) to deploy the Instance
Select your Instance Type. (Note:Select s3.large.2 or larger.).
Choose an Image. Under Public Image, select the Windows Server 2019 Datacenter 64bit English image
1. For Configure Network, select your VPC.
2. For Subnet, select an Subnet that you want to use, select Manually-specified IP address and input the IP address that you want to use
3. Select the Security Group to use or Edit and select an existing one.
4. Assign an EIPif you need the ECS instance to access the internet
5. Click Configure Advanced Settings and provide a name for the ECS, use Password for Login Mode and provide the secure password for Administrator login
6. Click Configure Now on Advanced Options Add a Tag to name your instance and Click on Confirm
Perform final review of the Instance and click on Submit.

*IMPORTANT: Make a note of this initial administrator password. It will be needed to log on to your instance.

Repeat the above steps for all instances.

Connect to Instances

You can connect to your domain controller instance via Remote Login from the ECS pane.

*BEST PRACTICE: Once logged on, it is best practice to change your password.

Configure the Domain Controller Instance

Now that the instances have been created, we started with setting up the Domain Service instance.

This guide is not a tutorial on how to set up an Active Domain server instance. We recommend reading articles on how to set up and configure an Active Directory server. It is very important to understand that even though the instance is running in a Huawei cloud, this is a regular installation of Active Directory.

Static IP Addresses

Configure Static IP Addresses for your Instances

Connect to your domain controller instance.
Click Start/ Control Panel.
Click Network and Sharing Center.
Select your network interface.
Click Properties.
Click Internet Protocol Version 4 (TCP/IPv4), then Properties.
Obtain your current IPv4 address, default gateway and DNS server for the network interface from Amazon.
In the Internet Protocol Version 4 (TCP/IPv4) Properties dialog box, under Use the following IP address, enter your IPv4 address.
In the Subnet mask box, type the subnet mask associated with your virtual private cloud subnet.
In the Default Gateway box, type the IP address of the default gateway and then click OK.
For the Preferred DNS Server, enter the Primary IP Address of Your Domain Controller(ex. 15.0.1.72).
Click Okay, then select Close. Exit Network and Sharing Center.
Repeat the above steps on your other instances.

Join the Two SQL Instances and the Witness Instance to Domain

*Before attempting to join a domain make these network adjustments. On your network adapter, Add/Change the Preferred DNS server to the new Domain Controller address and its DNS server. Use ipconfig /flushdns to refresh the DNS search list after this change. Do this before attempting to join the Domain.

*Ensure that Core Networking and File and Printer Sharing options are permitted in Windows Firewall.

On each instance, click Start, then right-click Computer and select Properties.
On the far right, select Change Settings.
Click on Change.
Enter a new Computer Name.
Select Domain.
Enter Domain Name– (ex. docs.huawei.com).
Click Apply.

*Use Control Panel to make sure all instances are using the correct time zone for your location.

*BEST PRACTICE: It is recommend that the System Page File is set to system managed (not automatic) and to always use the C: drive.

Control Panel > Advanced system settings > Performance > Settings > Advanced > Virtual Memory. Select System managed size, Volume C: only, then select Set to save.

Assign Secondary Private IPs to the Two SQL Instances

In addition to the Primary IP, you will need to add three additional IPs (Secondary IPs) to the elastic network interface for each SQL instance.

From the Service List dropdown, select Elastic Cloud Server.
Click the instance for which you want to add secondary private IP addresses.
Select NICs > Manage Virtual IP Address.
Click on Assign Virtual IP address and select Manual enter an IP address that is within the subnet range for the instance (ex. For 15.0.1.25, enter 15.0.1.26). Click Ok.
Click on the More dropdown on the IP address row, and select Bind to Server, select the server to bind the IP address to, and the NIC card.
Click OK to save your work.
Perform the above on both SQL Instances.

*HELPFUL LINKS:
Managing Virtual IP Addresses
Binding a Virtual IP Address to an EIP or ECS

Create and Attach Volumes

DataKeeper is a block-level volume replication solution and requires that each node in the cluster have additional volume(s) (other than the system drive) that are the same size and same drive letters. Please review Volume Considerations for additional information regarding storage requirements.

Create Volumes

Create two volumes in each availability zone for each SQL server instance, a total of four volumes.

From the Service List dropdown, select Elastic Cloud Server.
Click the instance for which you want to manage
Go to the Disks tab
Click Add Disk to add a new volume of your choice and size, make sure you select the volume in the same AZ as the SQL server that you intend to attach it to
Select the check box to agree to the SLA and Submit
Click Back to Server Console
Attach the disk if necessary to the SQL instance
Do this for all four volumes.

*HELPFUL LINKS:
Elastic Volume Service

Configure the Cluster

Prior to installing DataKeeper Cluster Edition, it is important to have Windows Server configured as a cluster using either a node majority quorum (if there is an odd number of nodes) or a node and file share majority quorum (if there is an even number of nodes). Consult the Microsoft documentation on clustering in addition to this topic for step-by-step instructions. Note: Microsoft released a hotfix for Windows 2008R2 that allows disabling of a node’s vote which may help achieve a higher level of availability in certain multi-site cluster configurations.

Add Failover Clustering

Add the Failover Clustering feature to both SQL instances.

Launch Server Manager.
Select Features in the left pane and click Add Features in the Features This starts the Add Features Wizard.
Select Failover Clustering.
Select Install.

Validate a Configuration

Open Failover Cluster Manager.
Select Failover Cluster Manager, select Validate a Configuration.
Click Next, then add your two SQL instances.

Note: To search, select Browse, then click on Advanced and Find Now. This will list available instances.

Click Next.
Select Run Only Tests I Select and click Next.
In the Test Selection screen, deselect Storage and click Next.
At the resulting confirmation screen, click Next.
Review Validation Summary Report then click Finish.

Create Cluster

In Failover Cluster Manager, click on Create a Cluster then click Next.
Enter your two SQL instances.
On the Validation Warning page, select No then click Next.
On the Access Point for Administering the Cluster page, enter a unique name for your WSFC Cluster. Then enter the Failover Clustering IP address for each node involved in the cluster. This is the first of the three secondary IP addresses added previously to each instance.
IMPORTANT!Uncheck the “Add all available storage to the cluster” checkbox. DataKeeper mirrored drives must not be managed natively by the cluster. They will be managed as DataKeeper Volumes.
Click Next on the Confirmation
On Summary page, review any warnings then select Finish.

Configure Quorum/Witness

Create a folder on your quorum/witness instance (witness).
Share the folder.
1. Right-click folder and select Share With / Specific People….
2. From the dropdown, select Everyone and click Add.
3. Under Permission Level, select Read/Write.
4. Click Share, then Done. (Make note of the path of this file share to be used below.)
In Failover Cluster Manager, right-click cluster and choose More Actions and Configure Cluster Quorum Settings. Click Next.
On the Select Quorum Configuration, choose Node and File Share Majority and click Next.
On the Configure File Share Witness screen, enter the path to the file share previously created and click Next.
On the Confirmation page, click Next.
On the Summary page, click Finish.

Install and Configure DataKeeper

After the basic cluster is configured but prior to any cluster resources being created, install and license DataKeeper Cluster Edition on all cluster nodes. See the DataKeeper Cluster Edition Installation Guide for detailed instructions.

Run DataKeeper setup to install DataKeeper Cluster Edition on both SQL instances.
Enter your license key and reboot when prompted.
Launch the DataKeeper GUI and connect to server.

*Note: The domain or server account used must be added to the Local System Administrators Group. The account must have administrator privileges on each server that DataKeeper is installed on. Refer to DataKeeper Service Log On ID and Password Selection for additional information.

Right click on Jobs and connect to both SQL servers.
Create a Job for each mirror you will create. One for your DTC resource, and one for your SQL resource..
When asked if you would like to auto-register the volume as a cluster volume, select Yes.

*Note: If installing DataKeeper Cluster Edition on Windows “Core” (GUI-less Windows), make sure to read Installing and Using DataKeeper on Windows 2008R2/2012 Server Core Platforms for detailed instructions.

Configure MSDTC

For Windows Server 2012 and 2016, in the Failover Cluster Manager GUI, select Roles, then select Configure Role.
Select Distributed Transaction Coordinator (DTC), and click Next.

*For Windows Server 2008, in the Failover Cluster Manager GUI, select Services and Applications, then select Configure a Service or Application and click Next.

On the Client Access Point screen, enter a name, then enter the MSDTC IP address for each node involved in the cluster. This is the second of the three secondary IP addresses added previously to each instance. Click Next.
Select the MSDTC volume and click Next.
On the Confirmation page, click Next.
Once the Summary page displays, click Finish.

Install SQL on the First SQL Instance

On the domain controller server create a folder and share it..
1. For example “TEMPSHARE” with Everyone permission.
Create a sub folder “SQL” and copy the SQL .iso installer into that sub folder.
On the SQL server, create a network drive and attach it to the shared folder on the domain controller.
- . For example “net use S: \\\TEMPSHARE
On the SQL server the S: drive will appear. CD to the SQL folder and find the SQL .iso installer. Right click on the .iso file and select Mount. The setup.exe installer will appear with the SQL .iso installer.

F:\>Setup /SkipRules=Cluster_VerifyForErrors /Action=InstallFailoverCluster

On Setup Support Rules, click OK.
On the Product Key dialog, enter your product key and click Next.
On the License Terms dialog, accept the license agreement and click Next.
On the Product Updates dialog, click Next.
On the Setup Support Files dialog, click Install.
On the Setup Support Rules dialog, you will receive a warning. Click Next, ignoring this message, since it is expected in a multi-site or non-shared storage cluster.
Verify Cluster Node Configuration and click Next.
Configure your Cluster Network by adding the “third” secondary IP address for your SQL instance and click Next. Click Yes to proceed with multi-subnet configuration.
Enter passwords for service accounts and click Next.
On the Error Reporting dialog, click Next.
On the Add Node Rules dialog, skipped operation warnings can be ignored. Click Next.
Verify features and click Install.
Click Close to complete the installation process.

Install SQL on the Second SQL Instance

Installing the second SQL instance is similar to the first one.

On the SQL server, create a network drive and attach it to the shared folder on the domain controller as explained above for the first SQL server.
Once the .iso installer is mounted, run SQL setup once again from the command line in order to skip the Validate Open a Command window, browse to your SQL install directory and type the following command:

Setup /SkipRules=Cluster_VerifyForErrors /Action=AddNode /INSTANCENAME=”MSSQLSERVER”

(Note: This assumes you installed the default instance on the first node)

On Setup Support Rules, click OK.
On the Product Key dialog, enter your product key and click Next.
On the License Terms dialog, accept the license agreement and click Next.
On the Product Updates dialog, click Next.
On the Setup Support Files dialog, click Install.
On the Setup Support Rules dialog, you will receive a warning. Click Next, ignoring this message, since it is expected in a multi-site or non-shared storage cluster.
Verify Cluster Node Configuration and click Next.
Configure your Cluster Network by adding the “third” secondary IP address for your SQL Instance and click Next. Click Yes to proceed with multi-subnet configuration.
Enter passwords for service accounts and click Next.
On the Error Reporting dialog, click Next.
On the Add Node Rules dialog, skipped operation warnings can be ignored. Click Next.
Verify features and click Install.
Click Close to complete the installation process.

Common Cluster Configuration

This section describes a common 2-node replicated cluster configuration.

The initial configuration must be done from the DataKeeper UI running on one of the cluster nodes. If it is not possible to run the DataKeeper UI on a cluster node, such as when running DataKeeper on a Windows Core only server, install the DataKeeper UI on any computer running Windows XP or higher and follow the instruction in the Core Only section for creating a mirror and registering the cluster resources via the command line.
Once the DataKeeper UI is running, connect to each of the nodes in the cluster.
Create a Job using the DataKeeper UI. This process creates a mirror and adds the DataKeeper Volume resource to the Available Storage.

!IMPORTANT: Make sure that Virtual Network Names for NIC connections are identical on all cluster nodes.

If additional mirrors are required, you can Add a Mirror to a Job.
With the DataKeeper Volume(s)now in Available Storage, you are able to create cluster resources (SQL, File Server, etc.) in the same way as if there were a shared disk resource in the cluster. Refer to Microsoft documentation for additional information in addition to the above for step-by-step cluster configuration instructions.

Connectivity to the cluster (virtual) IPs

In addition to the Primary IP and secondary IP, you will also need to configure the virtual IP addresses in the Huawei Cloud so that they can be routed to the active node.

From the Service List dropdown, select Elastic Cloud Server.
Click on one of the SQL instance for which you want to add cluster virtual IP address (one for MSDTC, one for SQL Failover Cluster)
Select NICs > Manage Virtual IP Address.
Click on Assign Virtual IP address and select Manual enter an IP address that is within the subnet range for the instance (ex. For 15.0.1.25, enter 15.0.1.26). Click Ok.
Click on the More dropdown on the IP address row, and select Bind to Server, select both the server to bind the IP address to, and the NIC card.
Use the same steps 4. and 5 for the MSDTC and SQLFC virtual IPs
Click OKto save your work.

Management

Once a DataKeeper volume is registered with Windows Server Failover Clustering, all of the management of that volume will be done through the Windows Server Failover Clustering interface. All of the management functions normally available in DataKeeper will be disabled on any volume that is under cluster control. Instead, the DataKeeper Volume cluster resource will control the mirror direction, so when a DataKeeper Volume comes online on a node, that node becomes the source of the mirror. The properties of the DataKeeper Volume cluster resource also display basic mirroring information such as the source, target, type and state of the mirror.
